Tdr Impedance Tester for Cable&Wire / Tdr Impedance Tester for FPC / PCB

Product Attributes:

Product name	TDR Impedance Test Instrument
Brand Name	ASIDA
Model Number	ZK2130
Place of Origin	China
Packaging Details	Wooden Carton

TDR Impedance Test Instrument USE:
TDR impedance test instrument is designed with time domain reflectometry, and is capable of batch, automation, rapid and accurate test of the characteristic impedance of PCB traces, test wave form analysis and statistical data analysis. The machine automatically records the test data and issues and prints a test report. For circuit board manufacturing, R&D, design, production and quality control unit. High frequency impedance test circuit board provides a fast, accurate, and economic solution to a high standard.

TDR Impedance Test Instrument Features:
1, Precision : Adopting high-precision
Probes, high frequency coaxial switch, and time-domain reflection,synchronous high-resolution sampling and multi-point calibration techniques.
2, Efficient:Test procedure integrated, multi-tasking one-button operation.
3, Specialties:Displays test waveform analysis, statistical data analysis, automatically record test data,
automatically generates test report and print, calibration open.

TDR Impedance Test Instrument Client:

Measuring accuracy	±1% (50Ω)
Detection rate	≤1s for every point
Objects	Controlled Impedance Measurement Range:20~150 Ω
	Measuring Range:0.05~2m
Wave Bandwidth	3GHz
